Precision Highlights

Tolerance
±10 μ
Diameter Range
1 mm – 180 mm
Max Machining Length
180 mm
Surface Finish
Ra ≤ 0.1, Rz ≤ 1
Geometrical Accuracy
Squareness ≤ 5 μ
Roundness ≤ 10 μ
Cylindricity ≤ 10 μ
Concentricity ≤ 10 μ

Infrastructure Highlights

  • CNC turning (single & multi-spindle)
  • 3-, 4- & 5-axis VMCs
  • Turn-O-Mill
  • Broaching & cylindrical grinding
  • EDM & wire cutting
  • Conventional: Traub, boring, drilling, thread rolling
  • Super finishing: Lapping, buffing, honing
Infrastructure Highlights

Our Capabilities

Materials Cast

Aluminum, Mild & Stainless Steel, Brass, Copper, Zinc, Phosphor Bronze, Inconel, Nickel, Special Alloys

Services Offered

Custom CNC Machining , Rapid Prototyping, Small to Large Batch Production

Frequently Asked Questions

What does the XINDUX Machining service cover?

It covers precision machined parts, turned parts, milled parts and industrial assemblies, with a project setup focused on industrial quality, manufacturability and reliable delivery.

Which processes are available?

The service includes CNC turning, milling, broaching, threading, Traub operations, EDM, wire cutting, boring, drilling, thread rolling, grinding and super-finishing.

Which technical capacity data is most relevant?

Key listed capability data: +/- 10 um tolerance class, 1-180 mm diameter range, 180 mm maximum machining length, Ra <= 0.1, Rz <= 1, squareness <= 5 um and roundness/cylindricity/concentricity <= 10 um.

Which equipment or infrastructure supports the service?

Relevant infrastructure includes single and multi-spindle CNC turning, 3/4/5-axis VMCs, Turn-O-Mill, broaching, cylindrical grinding, EDM, wire cutting, lapping, buffing and honing.

Which materials can be processed?

Typical materials include aluminium, mild steel, stainless steel, brass, copper, zinc, phosphor bronze, Inconel, nickel and special alloys.

When is this service the best technical choice?

It is strongest for high-tolerance components where repeatability, surface quality and process control are commercially decisive.

How does this service support cost-efficient production?

Cost is optimized by matching the process to geometry, quantity, tolerance, material behavior and required post-processing before release.

How does XINDUX reduce engineering risk?

Risk is reduced through early design review, process selection, tolerance review, tooling/manufacturing planning and alignment of inspection requirements.

Can XINDUX support DFM or process consulting?

Yes. Design-for-manufacturability review can identify geometry risks, avoid unnecessary tolerance cost and improve first-pass production quality.

Can prototypes and serial production both be supported?

Yes. The service setup supports early prototypes, validation batches and scalable production, depending on process and tooling route.

How is quality controlled?

Quality control can include datum strategy, tolerance stack-up control, surface finish checks, dimensional inspection and finishing layer verification.

Can post-processing be included?

Yes. Available post-processing or delivery options include rapid prototyping, small to large batch production, coating, assembly-ready delivery and fully finished parts.

Can parts be delivered assembly-ready?

Yes. Depending on the project, parts can be supplied post-processed, inspected, coated, machined, welding-ready or ready for final assembly.

How does this service help purchasing teams?

It reduces supplier fragmentation by combining technical process knowledge, production capability and finishing/inspection options under one coordinated supply chain.

How does this service help engineering teams?

Engineering teams receive clearer process boundaries, manufacturability feedback, CAD/CAM or tooling input and a more realistic path from drawing to production.

What should be clarified before quotation?

Material grade, annual quantity, tolerance class, critical dimensions, surface finish, test requirements, delivery condition and target application should be clarified.

Which files should be supplied for a quotation?

STEP or native 3D data, 2D PDF drawings, material specifications, quantities, finish requirements and inspection standards should be provided.

How can lifecycle cost be reduced?

Lifecycle cost is reduced by selecting the right process early, avoiding over-tolerancing, planning finishing correctly and reducing rework between suppliers.

Can the service be combined with other XINDUX capabilities?

Yes. It can be combined with machining, surface treatment, tooling, casting, forging, sheet metal fabrication or assembly, depending on the component route.

What is the main sales value for OEM customers?

OEMs gain a technically guided manufacturing route with fewer interfaces, better process compatibility, stronger quality control and faster movement from concept to delivery.
